SKU: MX102
Bayview 3-1/2 Inch Colonial Exterior Window & Door Trim
$35.67 per 8' Length ($4.46/Ft)
The Bayview is a 3-1/2 inch Colonial exterior window and door trim with a sloped top designed to move water away from the opening.
That angled top edge leads into a full rounded nose, a small fillet and cove, and a curved base that settles to 9/16 inch. With 1-7/8 inches of projection, it has the weight of traditional brick molding in a compact size.
Wood brick molding fails where water sits on top, and PVC brick molding expands in the sun and pulls away at the corners. The Bayview's slope and cement coated finish keep it dry and dimensionally stable on brick, stone, stucco and EIFS.
Material Summary
- Core: Lightweight EPS foam core (ASTM C578 Type I)
- Reinforcement: Alkali-resistant fiberglass mesh
- Finish: Polymer-modified cementitious coating, approx. 3/16 in thick
Engineered for near-zero joint expansion and moisture-inert performance.
Technical Specifications +
Profile: 3-1/2 inches high, 1-7/8 inches top depth, 9/16 inches bottom depth.
Core Material: EPS foam core (ASTM C578 Type I) with a polymer-modified cementitious coating, approx. 3/16 in thick, reinforced with alkali-resistant fiberglass mesh.
Moisture & Movement: Moisture-inert core that won't rot; near-zero joint expansion; designed for freeze-thaw exposure.
Weight: A fraction of the weight of precast concrete. Standard lengths can be installed by one person, with no heavy wall reinforcement or lifting equipment.
Installation: Exterior adhesive, with mechanical fasteners where the Mouldex installation guidelines require. For stucco, EIFS, brick, stone veneer, siding and ICF.
Finishing: Arrives in a uniform cement-gray finish. Prime, then paint with a quality exterior acrylic latex paint or texture.
Fire: Fire-rated options are available on request with a Class A fire rating (flame spread 25, smoke developed 110) that helps meet ASTM E-84 and UL 263.
Customization: CNC-cut to custom profiles, arches and ellipticals, typically within 7 to 10 business days of design approval.
Exterior Moldings Summary
Inorganic Composition
Moisture-inert. Won't rot or warp, and less susceptible to cracking.
Versatile Compatibility
Expertly bonds to Brick, Stone, Stucco, Vinyl, and ICF.
Bespoke Customization
Custom profiles, including arches and curves.
Unmatched Finish
Mimics smooth-sanded wood or textured masonry with ease.
Lifetime Stability
Dimensionally stable through freeze-thaw and seasonal swings.
Weight Efficiency
A fraction of the weight of stone. Usually no structural upgrades needed.
EXTERIOR PERFORMANCE COMPARISON
| Attribute | Mouldex Exterior Mouldings | Pre-Cast Concrete | Wood | PVC / Polyurethane |
|---|---|---|---|---|
| Weight | Ultra-Light (a fraction of the weight of precast) | Extremely Heavy | Moderate | Light |
| Durability | Polymer-Cement (Impact Resistant) | Masonry (Brittle) | Prone to Rot/Warp | High Expansion |
| Installation | 1-Person / No Cranes | Crane / Structural Ties | Skilled Carpentry | Standard Mechanical |
| Maintenance | Primed & Painted; Low Upkeep | Patching / Re-sealing | Painting / Staining | Fading / Chalking |
Additional Comparison: Foam Core vs Cement Coated Moldings
Complete Exterior Moulding System Line
Our exterior mouldings are made to stand up to outdoor conditions while adding detail and protection to building facades, as a lightweight alternative to traditional exterior moulding materials such as precast concrete, wood, MDF and PVC. From window trim and door trim to window sills and crown and cornice mouldings, every profile shares the same moisture-inert core, near-zero joint expansion and low-maintenance finish.
